Top Mount Tank Power Units
Highly Customizable: Several valve and component options.
Pump and Motor Accessible: Ability to replace easily.
Easy Reservoir Draining: Pump not required for draining.
In-Tank Filter System: Provides easy element replacement without line drainage.
Convenient Suction Strainer Maintenance: Clean out access cover allows replacement of suction strainer without draining reservoir.
Removable Top Plate: Allows for easy reservoir cleaning. No leaky end bells that make access for cleaning difficult.
Conserves Space: While still allowing easy maintenance, the top mount tank design saves floor space.
|
Model Number |
Tank Size |
Motor HP |
Pump Type / Flow | Pressure | Price |
Case Drain Cooler |
AC8-3 Cooler |
ACD16-3 Cooler |
AC30-3 Cooler |
1/2HP 3PH Fan |
|---|---|---|---|---|---|---|---|---|---|---|
| TMT10-5HPC3-G1.9 | 10 GAL. | 5 | Gear 1.9 GPM | 3000 PSI | $2,380 | N/A | $950 | $1,300 | N/A | N/A |
| TMT10-5HPC3-G3.0 | 10 GAL. | 5 | Gear 3.0 GPM | 2500 PSI | $2,300 | N/A | $950 | $1,300 | N/A | N/A |
| TMT10-5HPC3-PCP4 | 10 GAL. | 5 | PC Piston 3.8 GPM | 2000 PSI | $2,540 | $275 | $950 | $1,300 | N/A | N/A |
| TMT10-5HPC3-PCP8 | 10 GAL. | 5 | PC Piston 7.9 GPM | 1000 PSI | $2,710 | $275 | $950 | $1,300 | N/A | N/A |
| TMT20-5HPC3-G3.0 | 20 GAL. | 5 | Gear 3.0 GPM | 2500 PSI | $2,700 | N/A | $950 | $1,300 | N/A | N/A |
| TMT20-5HPC3-PCP4 | 20 GAL. | 5 | PC Piston 3.8 GPM | 2000 PSI | $2,940 | $275 | $950 | $1,300 | N/A | N/A |
| TMT20-5HPC3-PCP8 | 20 GAL. | 5 | PC Piston 7.9 GPM | 1000 PSI | $3,110 | $275 | $950 | $1,300 | N/A | N/A |
| TMT20-7.5HPC3-G4.5 | 20 GAL. | 7.5 | Gear 4.5 GPM | 2500 PSI | $2,930 | N/A | $950 | $1,300 | N/A | N/A |
| TMT20-7.5HPC3-G4.5 | 20 GAL. | 7.5 | Gear 4.5 GPM | 2500 PSI | $2,930 | N/A | $950 | $1,300 | N/A | N/A |
| TMT20-10HPC3-PCP8 | 20 GAL. | 10 | PC PISTON 7.9 GPM | 2000 PSI | $3,470 | $275 | $950 | $1,300 | N/A | N/A |
| TMT20-10HPC3-G16 | 20 GAL. | 10 | Gear 16 GPM | 1000 PSI | $3,530 | N/A | $950 | $1,300 | N/A | N/A |
| TMT20-10HPC3-PCP16 | 20 GAL. | 10 | PC Piston 16 GPM | 1000 PSI | $3,960 | $275 | $950 | $1,300 | N/A | N/A |
| TMT35-7.5HPC3-G4.5 | 35 GAL. | 7.5 | Gear 4.5 GPM | 2500 PSI | $3,240 | N/A | $950 | $1,300 | N/A | N/A |
| TMT35-10HPC3-PCP8 | 35 GAL. | 7.5 | PC Piston 7.9 GPM | 1500 PSI | $3,600 | $275 | $950 | $1,300 | N/A | N/A |
| TMT35-10HPC3-G16 | 35 GAL. | 10 | Gear 16 GPM | 1000 PSI | $3,780 | N/A | $950 | $1,300 | N/A | N/A |
| TMT35-10HPC3-PCP16 | 35 GAL. | 10 | PC Piston 16 GPM | 1000 PSI | $4,210 | $275 | $950 | $1,300 | N/A | N/A |
| TMT35-15HPC3-G16 | 35 GAL. | 15 | Gear 16 GPM | 1500 PSI | $4,100 | N/A | $950 | $1,300 | N/A | N/A |
| TMT35-15HPC3-PCP16 | 35 GAL. | 15 | PC Piston 16 GPM | 1500 PSI | $4,270 | $400 | $950 | $1,300 | N/A | N/A |
| TMT70-20HPC3-G16 | 70 GAL. | 20 | Gear 16 GPM | 2000 PSI | $4,920 | N/A | $950 | $1,300 | N/A | N/A |
| TMT70-20HPC3-PCP16 | 70 GAL. | 20 | PC Piston 16 GPM | 2000 PSI | $5,410 | $400 | $950 | $1,300 | N/A | N/A |
| TMT70-25HPC3-G16 | 70 GAL. | 25 | Gear 16 GPM | 2500 PSI | $5,300 | N/A | $950 | $1,300 | N/A | N/A |
| TMT70-25HPC3-PCP16 | 70 GAL. | 25 | PC Piston 16 GPM | 2500 PSI | $5,800 | $400 | $950 | $1,300 | N/A | N/A |
| TMT70-25HPC3-PCP33 | 70 GAL. | 25 | PC Piston 33 GPM | 1200 PSI | $6,300 | $400 | $950 | $1,300 | $1,800 | N/A |
| TMT70-30HPC3-G16 | 70 GAL. | 30 | Gear 16 GPM | 2900 PSI | $5,320 | N/A | $950 | $1,300 | $1,800 | N/A |
| TMT70-30HPC3-PCP21 | 70 GAL. | 30 | PC Piston 21 GPM | 2200 PSI | $6,050 | $400 | N/A | $1,300 | $1,800 | N/A |
| TMT70-30HPC3-PCP33 | 70 GAL. | 30 | PC Piston 33 GPM | 1400 PSI | $6,500 | $400 | N/A | $1,300 | $1,800 | N/A |
| TMT70-40HPC3-G24 | 70 GAL. | 40 | Gear 24 GPM | 2000 PSI | $6,180 | N/A | N/A | $1,300 | $1,800 | N/A |
| TMT70-40HPC3-PCP21 | 70 GAL. | 40 | PC Piston 21 GPM | 3000 PSI | $6,500 | $400 | N/A | $1,300 | $1,800 | N/A |
| TMT70-40HPC3-PCP33 | 70 GAL. | 40 | PC Piston 33 GPM | 1900 PSI | $6,910 | $400 | N/A | $1,300 | $1,800 | N/A |
| TMT70-50HPC3-G29 | 70 GAL. | 50 | Gear 24 GPM | 2700 PSI | $6,670 | $400 | N/A | $1,300 | $1,800 | N/A |
| TMT70-50HPC3-PCP33 | 70 GAL. | 50 | PC Piston 33 GPM | 2400 PSI | $7,610 | $400 | N/A | $1,300 | $1,800 | N/A |
| TMT70-50HPC3-PCP47 | 70 GAL. | 50 | PC Piston 47 GPM | 1700 PSI | $8,540 | $400 | N/A | N/A | $1,800 | N/A |
| TMT70-50HPC3-PCP64 | 70 GAL. | 50 | PC Piston 64 GPM | 1200 PSI | $9,620 | $440 | N/A | N/A | $1,800 | N/A |
| ADDERS | ||||||||||
| 1.5 KW HEATER $490 | ||||||||||
| FLOAT SWITCH $140 | ||||||||||
| TEMP SWITCH $140 | ||||||||||
| 100 GAL ADD $420 | ||||||||||
| 150 GAL ADD $1,220 |
