L Style Tank Power Units

Lower Profile: Unit can be mounted under work tables, conveyors, etc. Easy access to pump and motor.
Easy Reservoir Draining: Pump not required for draining. Drain ball valve provided.
Flooded Suction: Longer pump life; pump always stays submersed. No pump rusting during shut-down periods. Air bleed valves are not required.
In-Tank Filter System: Provides easy element replacement without line drainage.
Removable Top Plate: Allows for easy reservoir cleaning. No leaky end bells that make access for cleaning difficult.
Self Flushing: System flushes any material in suction line when pump is replaced.
Convenient Suction Strainer Maintenance: Clean out access cover allows replacement of suction strainer without draining reservoir.
Integral Drip Pan: Pump/ motor mounting area serves as drip pan. Drain ball valve included standard.

Model
Number
Tank
Size
Motor
HP
Pump
Type / Flow
PressurePriceCase
Drain
Cooler
HeaterAC8-3
Cooler
ACD16-3
Cooler
AC30-3
Cooler
1/2HP
3PH
Fan
LT20-5HPC3-G3.020 GAL.5Gear 3.0 GPM2500 PSI$2,990N/A1.5KW $411$940$1,270N/A$620
LT20-5HPC3-PCP420 GAL.5PC Piston 3.8 GPM2000 PSI$3,230$2201.5KW $411$940$1,270N/A$620
LT20-5HPC3-PCP820 GAL.5PC Piston 3.8 GPM1000 PSI$3,395$2201.5KW $411$940$1,270N/A$620
LT20-7.5HPC3-G4.520 GAL.7.5Gear 4.5 GPM2500 PSI$3,215N/A1.5KW $411$940$1,270N/A$620
LT20-7.5HPC3-PCP820 GAL.7.5PC Piston 7.9 GPM1500 PSI$3,575$2201.5KW $411$940$1,270N/A$620
LT20-10HPC3-PCP820 GAL.10PC Piston 7.9 GPM2000 PSI$3,775$2201.5KW $411$940$1,270N/A$620
LT20-10HPC3-G1620 GAL.10Gear 16 GPM1000 PSI$3,615N/A1.5KW $411$940$1,270N/A$620
LT20-10HPC3-PCP1620 GAL.10PC Piston 16 GPM1000 PSI$4,250$2201.5KW $411$940$1,270N/A$620
LT35-7.5HPC3-G4.535 GAL.7.5Gear 4.5 GPM2500 PSI$3,625N/A1.5KW $411$940$1,270N/A$620
LT35-10HPC3-PCP835 GAL.7.5PC Piston 7.9 GPM1500 PSI$3,985$2201.5KW $411$940$1,270N/A$620
LT35-10HPC3-G1635 GAL.10Gear 16 GPM1000 PSI$4,165N/A1.5KW $411$940$1,270N/A$620
LT35-10HPC3-PCP1635 GAL.10PC Piston 16 GPM1000 PSI$4,595$2201.5KW $411$940$1,270N/A$620
LT35-15HPC3-G1635 GAL.15Gear 16 GPM1500 PSI$4,480N/A1.5KW $411$940$1,270N/A$620
LT35-15HPC3-PCP1635 GAL.15PC Piston 16 GPM1500 PSI$4,655$3201.5KW $411$940$1,270N/A$620
LT70-20HPC3-G1670 GAL.20Gear 16 GPM2000 PSI$5,735N/A1.5KW $411$940$1,270N/A$715
LT70-20HPC3-PCP1670 GAL.20PC Piston 16 GPM2000 PSI$6,230$3201.5KW $411$940$1,270N/A$715
LT70-25HPC3-G1670 GAL.25Gear 16 GPM2500 PSI$6,120N/A1.5KW $411$940$1,270N/A$715
LT70-25HPC3-PCP1670 GAL.25PC Piston 16 GPM2500 PSI$6,610$3201.5KW $411$940$1,270N/A$715
LT70-25HPC3-PCP3370 GAL.25PC Piston 33 GPM1200 PSI$7,115$3201.5KW $411$940$1,340$1,760$715
LT70-30HPC3-G1670 GAL.30Gear 16 GPM2900 PSI$6,140N/A1.5KW $411$940$1,270$1,760$715
LT70-30HPC3-PCP2170 GAL.30PC Piston 21 GPM2200 PSI$6,865$3201.5KW $411N/A$1,340$1,760$715
LT70-30HPC3-PCP3370 GAL.30PC Piston 33 GPM1400 PSI$7,320$3201.5KW $411N/A$1,340$1,760$715
LT70-40HPC3-G2470 GAL.40Gear 24 GPM2000 PSI$6,995N/A1.5KW $411N/A$1,340$1,760$715
LT70-40HPC3-PCP2170 GAL.40PC Piston 21 GPM3000 PSI$7,320$3201.5KW $411N/A$1,340$1,760$715
LT70-40HPC3-PCP3370 GAL.40PC Piston 33 GPM1900 PSI$7,730$3201.5KW $411N/A$1,340$1,760$715
LT70-50HPC3-G2970 GAL.50Gear 24 GPM2700 PSI$7,490$3201.5KW $411N/A$1,340$1,760$715
LT70-50HPC3-PCP3370 GAL.50PC Piston 33 GPM2400 PSI$8,425$3201.5KW $411N/A$1,340$1,760$715
LT70-50HPC3-PCP4770 GAL.50PC Piston 47 GPM1700 PSI$9,360$3201.5KW $411N/AN/A$1,760$715
LT70-50HPC3-PCP6470 GAL.50PC Piston 64 GPM1200 PSI$10,440$4401.5KW $411N/AN/A$1,760$715
ADDERS
Float Switch $140
Temp Switch $140
100 Gal Add $420
150 Gal Add $1,220
